33006 Kyosho – 1/8 Audi R8 LMS Red With KT-331P 4WD Inferno GT2 R/S Readyset

Powered by the fuel-efficient and user-friendly KE25 engine, this popular big scale GT machine based on the Inferno GT2 Race Spec has been tuned up for even greater performance to deliver speeds over 70km/h. While keeping all the main chassis components unchanged, the adoption of the front C of G type radio box from the MP9 uses optimal weight balance to increase grip and improve overall running performance. With aluminum parts anodized in Kyosho’s signature gun metal, the GT2 presents a formidable racing image. Like other similar to other mid-range transmitters, the included Syncro 2.4GHz KT-331P transmitter automatically manages frequency bands and features LCD screen, jog dials, model selection (up to 15), endpoint adjustment, dual-rate and exponential settings. New servos deliver both high-torque and high-speed for superior control. Packaged as a Readyset, you can enjoy the power and performance of this big machine as soon as you buy it.

Front center gravity type radio box improves running stability and safety.

Includes Syncro KT-331P transmitter that allows precision setting adjustments.

Newly equipped with high torque KS5031-09MW metal-geared servo.

Equipped with resin chassis stiffener as standard.

High-power output combination of KE25 engine + polished muffler + manifold.

3PC clutch included as standard.

Long wheelbase contributes to excellent running stability and improved scale feel.

Features dual disc brake system that delivers high fade resistance.

Setting alignment can be adjusted with turnbuckle upper arms and tie rods.

150cc fuel tank delivers long run times.

34mm small flywheel realizes sharp throttle response.

Torque rod installed on front/rear as standard.

Features spiral type ring & pinion gear on front/rear diff.

Full ball bearing specifications include 18 on drive train and 2 on clutch bell.

TECHNICAL DATA

• Length 515mm
• Width 310mm
• Height 135mm
• Wheelbase 360mm
• Tread (F/R) 262mm/265mm
• Tire(F/R) Φ97mm ×48mm
• Gear Ratio 1st 10.14:1, 2nd 7.49:1
• Weight 3,650g (approx.)
• Engine KE25
• R/C System KT-331P

KIT CONTENTS

• Pre-assembled chassis installed with 2-ch, 2-servo R/C system and pre-set control linkages
• Pre-painted factory assembled body with decals applied
• Installed KE25 rear exhaust engine
• Installed polished tuned muffler
• Syncro KT-331P transmitter
• Hex wrenches: 1.5, 2.0, 2.5, 3.0mm
• Cross wrench (large)
• 17mm wheel wrench
• Nylon strap (for air cleaner)

REQUIRED FOR OPERATION

• 8 x AA batteries for transmitter (4) and receiver (4)
• Fuel
• Engine starting tools (fuel bottle, plug heater)
