350202 XRAY XT9 – 1/8 Luxury Racing Truggy

• Class: 1/8 nitro truggy
• Length w/o body: 574 mm
• Chassis length: 452 mm
• Wheelbase: 376-388 mm
• Width: 428 mm front; 430 mm rear
• Weight: 2333 gr
• Ready-to-run weight: approx. 3681g

Chassis

• Chassis: CNC-machined 3.0 mm Swiss 7075 T6 aluminum
• Shock towers: machined laminated carbon graphite (front + rear) with multiple shock mounting and roll center positions
• Radio tray: composite one piece

Drivetrain

• Type: Full-time shaft-drive 4WD w/ center differential
• Drive shafts: CVD drive shafts – Hudy Spring Steel™
• Final drive ratio (FDR): 15.88:1
• Differentials: Sealed, 6 gear, silicone-filled
• Front differential: 43T
• Center differential: 48T
• Rear differential: 43T
• Clutch bell: 13T
• Clutch: Aluminum 3-shoe

Suspension

• Suspension: Adjustable suspension with preset geometry
• Rear suspension: Lower H-arm with adjustable upper camber link
• Front suspension: Zero Kingpin suspension with integrated adjustable caster
• Rear upright: Composite with dual arm mounting and 3 roll center positions
• Shocks: Big-bore, long-travel shocks, machined aluminum, oil-filled, coil-over shocks

Adjustability

• Caster: adjustable front + rear
• Camber: adjustable front + rear
• Toe: adjustable front + rear
• Kick-Up: adjustable front
• Anti-squat: adjustable rear
• Ride height: adjustable front + rear
• Downstops: adjustable front + rear
• Track-width: adjustable front + rear
• Front anti-roll bars: Wire style 2.4 mm
• Rear anti-roll bar: Wire style 2.8 mm
• Roll center: adjustable front + rear, upper & lower
• Bump steer: adjustable front
• Wheelbase: adjustable front & rear
• Ackermann: adjustable front
• Shocks: Adjustable damping, preload, mounting positions

Equipment

• Body: XRAY XT8 body
• Wheels: XRAY Racing Dish Wheels
• Tires: XRAY Thrax low-profile tires with foam inserts
• Fuel tank: 150cc capacity with hypertonic tank lid and internal stone-type filter and fuel tank pressure cap with 1-piece profiled seal
• Instructions: Instruction Manual with 3D graphics (44 pages)
• Packaging: carton box with vinyl bags with parts
• Additionally included: Authentication Certificate, set-up sheet, parts list & exploded view, decals
• Not included: radio system (transmitter and receiver), personal transponder, steering & throttle servos, engine, manifold & exhaust, starter box & starter box battery pack, receiver battery pack, glowplug igniter, battery charger, Lexan® paint, model R/C car fuel (nitromethane), tape, CA glue, bearing oil, medium-grade (blue) threadlock, tools, Set-up book: 2-color Set-Up Book (39 pages) – not included
