58280 Tamiya – 1/8 TXT-1 TAMIYA XTREME TRUCK

The TXT-1 is designed like
a full size monster truck with an aluminum ladder frame and multi-link
suspension. Solid axles with a cantilever system allows for massive suspension
articulation. This kit includes hardware and a second servo saver for four wheel
steering. The servo (or servos) are located next to the axle for direct
steering. Kit requires a 2 or 3 channel radio and can operate on a 7.2V or 8.4V
battery.

Feel the Power of Twin Motor 4WD!
This R/C machine packs
all the power of an American Monster Truck. Tamiya invites you to feel the
rumble of parallel twin motors transferring power to the propeller shaft and
front/rear axles as this bad-boy takes on extreme 4×4 off-road action.

Heavy-duty Parts for Rugged Driving
Aluminum side frames
and suspension arms add a customized feel and ensure high durability. The TXT-1
features a 2-level gearbox for efficient power transmission.

High Performance Wheels
The 4-link rigid wheels
feature push rods and locking arms as well as dampers that employ cantilever
suspension. The extraordinary suspension stroke and monster tires allow the
TXT-1 to handle the hardest of roads.

510mm Giant

This gargantuan R/C
truck has a total length of 510mm and a total width of 385mm. The model emulates
the crushing power demonstrated by real-sized American monster tucks as they
pound their way over rows of junkyard cars. This unique colossus needs no roads,
simply grab the transmitter and watch as the TXT-1 paves a path of its own.

See the powerful TXT-1 in action!

Now you can check out the
TXT-1&39;s hardcore off-road performance with just the click of your mouse. The
TXT-1&39;s sheer power lets it tackle the harshest terrain- no roads, no problem.
But don&39;t just take our word for it, click on the link below to check it out!

Basic Specifications

• Overall length: 510mm, Overall width: 385mm,
  Overall height: 297mm
• Minimum clearance: 49mm
• Weight fully equipped: 5,010g (including
  TP-S3003 servo x 2, TP-R122JE receiver, and RC2400SP battery)
• Wheel base: 330mm
• Tread (front and rear): 280mm
• Chassis material: aluminum
• Chassis type: ladder frame
• Steering tie rods: divided in two segments
• Suspension (front and rear): 4-link rigid
• Caster angle (f/r): 0 deg.
• Camber angle (f/r): 0 deg.
• Toe angle (f/r): 0 deg.
• Dampers (f/r): CVA damper
• Drive train: shaft drive 4WD
• Gear ratio: 34:1
• (2) type 540 motors
• Diff gear system (f/r): 3 bevel diff
• Speed controller: 3-step speed controller
• Tire width (f/r): 106mm
• Tire diameter (f/r): 165mm
• Tire pattern (f/r): Lug pattern

Required Items (Sold Separately)

• R/C Unit: Adspec GT-II or 2 channel 2
  servo-type transmitter
• Battery: Tamiya 7.2V battery
• Receiver batteries: (4) R6/AA/UM3
• Transmitter batteries: (8) R6/AA/UM3

*Caution: Amplifier/CPR Unit cannot be
used.

�ELECTRIC KITS REQUIRE:
(unless stated differently
above)

• Radio: 2-Channel with servo(s)
• Battery: 6-cell flat with standard Tamiya
  connector
• Charger: AC/DC timed or peak for 6-cell
  battery
• Paint: PS for Polycarbonate/TS for ABS
• Misc. Items: Building and track equipment
