58665 Tamiya – 1/10 Toyota Gazoo Racing TS050 Hybrid (F103GT Chassis)

F103GT – Fun, Responsive Direct Drive! The F103GT chassis utilizes 2WD direct drive, with a rear-mounted motor. Its FRP double-deck frame employs 1.5mm upper and 2.5mm lower decks, cushioned by link-type arm and coil spring left/right independent front suspension. An FRP T-bar is the centerpiece of the rigid rear suspension setup, working in tandem with the friction plate and coil spring unit to provide a smooth drive. The height adjustable gear case allows a range of ground clearance settings, and contains a high-performance ball differential. Front uprights give a 3° caster angle, and are equipped with 850 ball bearings. Get ready for a fun, responsive drive! SpecificationsLength: 418mm, Width: 188mm, Height: 115mm

Wheelbase: 257mm

Tread: 156mm (Front & Rear)

Tire Width/Diameter: 26/66mm (Front & Rear)

FRP Double-Deck Frame

Direct Drive 2WD

Ball Differential

2-Piece Steering Tie-Rod

Suspension: Kingpin Coil Sprung Independent L/R (Front), Rigid Type with FRP T-Bar and Friction Damper (Rear)

Gear Ratio = 5.00:1

Type 540 Motor

Electronic Speed Controller (ESC) is sold separately. Separately Required Items2-Channel R/C System w/ESC

R6/AA/UM3 batteries for transmitter

Battery Pack & Charger
