84432 Tamiya – 1/10 TRF102 Black Edition Chassis Kit

This is a “BLACK EDITION” of the TRF102 Formula One Chassis kit. All the aluminum parts are anodized in black, whereas the original kit was anodized in the world-famous Tamiya Blue.

The TRF102 is the second-generation high-performance Formula One chassis designed by Tamiya’s elite designers. This iteration is a revolution! The kit features a number of changes to provide superior performance especially with rubber tire applications and outdoor track use. Both the front and rear of the car have been redesigned to fully utilize the flexibility of the chassis, with the effect of excellent road holding and response.
Key Design Points:

The New T-Bar design provides a progressive roll damping effect superior to that offered by the spring-actuated side links on the TRF101. The roll point ball has been placed in as low a position as possible, in order to maximize damping effect. 2 thicknesses of T-bar (1.5mm and 1.8mm) are included.

The brand-new pitch axle gives vastly improved, independent pitch damping, letting the chassis deal much more smoothly with undulating surfaces.

Servo mount screws are attached closer together on the lower deck. This, in combination with the floating battery mount, allows greater expression of lower deck flexibility, giving the feeling of greater stroke at the front of the car. A new servo stiffener keeps the servo firmly in place.

Slits are cut into the lower deck to further enhance its flexibility.

The roll damper has been moved closer to the lower deck, giving a more compact rear and contributing to the chassis’ low center of gravity.

TRF102 Carbon Lower (2.5mm Thick) & Upper (2.0mm Thick) Decks

TRF102 Aluminum Motor Mount

F104 Low-Friction Suspension Balls

Reinforced Carbon Reinforced Plastic Front Suspension Arms

TRF102 T-Bar Rear Suspension

Adjustable Metal Upright Set

Integrated Diff Plate/Carbon Rear Shaft

TRF102 Aluminum Servo Stay

1.5mm & 1.8mm T-bars

Hi-Torque Servo Saver

TRF Damper

Specifications

• Scale : 1/10
• Construction type : Assembly kit
• Terrain use : On-Road
• Drive-train : 2WD RWD
• Drive type : Pinion to spur gear
• Drive line : Solid axle
• Differential type : Ball pressure plate
• Suspension : Front kingpin coil spring independent suspension/solid axle rear
• Steering mechanism : Direct servo
• Shock damper : Oil-filled damper
• Shock damper material : Aluminum
• Tire type : Not included
• Tire tread : N/A
• Body material : Not included
• Chassis material : Carbon fiber plate
• Electronic Speed Control (ESC) : Not included
• ESC model : N/A
• LED Light buckets : No
• LED lights : No
• Motor : Not included
• Bearings : Flourine-Coated Ball Bearings
• Adjustable camber : Fixed
• Adjustable toe angles : Front only
• Adjustable ground clearance : Yes
• Adjustable gear ratio : Yes
• Adjustable wheelbase : Fixed
• Adjustable track width : Fixed
• Adjustable shock angle : Yes

Features

• TRF102 Carbon Lower (2.5mm Thick) & Upper (2.0mm Thick) Decks
• TRF102 Carbon Lower (2.5mm Thick) & Upper (2.0mm Thick) Decks
• F104 Low-Friction Suspension Balls
• Reinforced Carbon Reinforced Plastic Front Suspension Arms
• TRF102 T-Bar Rear Suspension
• Adjustable Metal Upright Set included
• Integrated Diff Plate/Carbon Rear Shaft
• TRF102 Aluminum Servo Stay
• 1.5mm & 1.8mm T-bars
• Aluminum parts come in black.

Requires

• 2-channel radio gear
• Polycarbonate paint
• 7.2 battery & charger
