Specifications:
Storage Temperature Range: -20℃~60℃
Operating Temperature Range: 0℃~50℃
Operating Voltage Range: 4.8V~6.0V
Gear Material: Titanium metal gear
Weight: ~45g
Dimension: 40.6mm (L) x 25.3mm(W) x 20mm(H)
Stall Torque: 7.0 kg-cm @4.8V, [email protected] Operating Speed(with no load): 0.07 sec/60°@4.8V, 0.06 sec/60°@6V
Dead band width: ~4 μsec
Usage/Warning Notes:
-Vibration when running may damage the servo. In order to reduce the vibration,
it is
better to use the provided rubber grommet to mount the servo to the mechanical
plates.
-Make sure to connect the servo lead connector to the receiver correctly. Improper
connection will let the servo not function or it may burn the circuit board
inside the
servo.
-Make sure the power line is connected tightly to the receiver. Otherwise, the
loose
connection may lead to the servo out of control.
-Do not turn the servo horn forcibly in the power on status. Otherwise, it may
damage
the gear part inside the servo.
-Do not use in the rain or in a location where the water get on it. The servo
may be out of
control when it becomes wet.
