R149DP Futaba 9-Channel PCM Rx 50MHz/ 72MHz High W/o Crystal

Futaba (#R149DP) – Futaba R149DP 9-Channel PCM Rx 72MHz High w/o Crystal

NOTES FROM OUR TECH DEPARTMENT
This is a R149DP 9-Ch 72MHz PCM 1024 Dual Conversion Receiver Without Crystal.
This is a High Band (channel 36-60) receiver without a crystal (see REQUIRES).

FEATURES: Narrow-band spacing and dual conversion signal filtering combined to
provide exceptionally clear, interference-free reception and
amazingly smooth, accurate control.
Designed for modelers who want to use a single radio transmitter
to fly several different model aircraft. Especially pilots who are
utilizing computerized radios with multi-model memory.

INCLUDES: One R149DP Miniature 9 Channel 72MHz PCM 1024 Receiver

REQUIRES: One FUTL58** Dual Conversion Receiver Crystal

SPECS: Narrow Band: 20KHz
Intermediate Frequency- 1st IF: 10.7MHz
2nd IF: 455kHz
Power Requirements: 4.8 to 6.0 volts (shared with servos)
Current Drain: 15mA
Length: 2.16″ (55.0mm)
Width: 1.27″ (32.0mm)
Height: 0.82″ (21.0mm)
Weight: 1.2 oz (36g)
COMMENTS: 1024 Resolution is NOT Compatible with Older PCM 512 Systems.
For the transmitter/receiver crystal set, use FUTL20**.
For the High Band, use FUTL0903.
Special Notice about Frequency Changes-
*72MHz- Low band channels 11 to 35; High band channels 36 to 60.
Receiver crystal channels (11-35 or 36-60) Within Each Band
Can Be Changed, and Do Not Require a retuning of the receiver.
*72MHz Frequency Band (low or high) for the receiver Can Not Be
Changed from low to high band, OR from high to low band without
sending it into Futaba Services for retuning.
*50MHz, 72MHz, 27MHz and 75MHz Frequency Bands Can Not under any
circumstances be interchanged with each other. 72/75:receiver Must
be sent in for retuning to the appropriate band. 50/27: can’t do.
*50MHz, 27MHz and 75MHz receiver crystals Can be changed anywhere
within the respective bands. There are no high or low bands such
as the 72MHz band has.
*Transmitter Crystals Can Not be changed to another channel except
by a licensed service center. It is against FCC regulations, and
illegal for the user to change a frequency determining component
of a transmitter. If the radio is not retuned, it can be a hazard
spectators, modelers or property, and void AMA insurance coverage.
*Check with the local R/C club for the frequencies used in your area
