S136G Futaba Compact Retract Servo

The S136G Compact Landing Gear Retract Servos are extra-flat
so they will fit into a wing.

This servo can produce high-current draw from your batteries.
If using NiMH or Li-Po batteries, make sure they are capable
of delivering sufficient Amps.

FEATURES: Two Ball Bearings
Metal Gear Set
3-pole motor
Compact Size
Travels 180 degrees – full-lock to full-lock — to hold your gear in
position securely. Not proportional. Perfect for mechanical
retract installation. (see COMMENTS)
One-Year Warranty.

INCLUDES: One S136G Compact Retract Servo w/ J Connector

SPECS: Length: 1.8″ (46mm)
Width: 0.9″ (23mm)
Height: 1.0″ (25mm)
Torque: 92 oz/in @ 4.8V (6.6 kg/cm @ 4.8V)
Speed: .58 seconds/60 degrees @ 4.8V (it actually travels 180 degrees
see COMMENTS)
Weight: 1.5 oz (42g)

COMMENTS: A retract servo is a very specialized servo. It is non-proportional,
going 180 degrees, “lock to lock”. They are specifically made for
mechanical retracts to lock the gear in the up and down positions.
and DO NOT have any means of end point adjustment and cannot be
adjusted by ATV on a transmitter. They are only able to go 180
degrees and provide full maximum available torque at the two end
points. This is their whole purpose and intentional design, but if
someone has a unique design situation where they need other than
180 degrees available, they must use a proportional servo, not a
retract servo. They are specifically designed to withstand constant
holding loads in the up and down positions, unique to the use of
mechanical retracts.
Pneumatic retracts do not need a retract servo. A proportional
standard or mini servo is used to move the air valve back and forth
